GT30K PLUS 30kva online uninterruptible power supply ups 480vac
Industrial UPS | 30kVA / 24kW | 3 Phase | 208Vac/220Vac/440Vac/480Vac | 384Vdc
Prostar GT30K PLUS 30kva online uninterruptible power supply ups 480vac can ensure uninterrupted power supply in critical applications. The online uninterruptible power supply boasts an impressive efficiency rating, reducing energy consumption and operational costs while maintaining optimal performance.
Utilizing advanced double-conversion technology, this online uninterruptible power supply provides a clean and stable output voltage, ensuring that connected equipment operates without interruption.
The GT30K PLUS offers multiple layers of protection, including overload, short circuit, and over-temperature safeguards, ensuring the safety of both the UPS and connected devices.
Online Uninterruptible Power Supply UPS Features
Double Conversion Topology
Ensures continuous, seamless power output, even during utility power failures.
Pure Sine Wave Output
Delivers clean power that is compatible with a wide range of electronic equipment.
LCD Display
Provides real-time status and diagnostic information.
User-Friendly Interface
Equipped with an intuitive LCD display, users can easily monitor the UPS status, battery health, and power conditions in real-time.
Parallel Capability
Allows for increased output capacity by connecting multiple units.
Uninterruptible Power Supply Diagram
Online UPS Touch LCD Information
Industrial UPS System Inner Components View
Applications
The GT30K PLUS is ideally suited for a wide range of applications, including:
- Data Centers: Protecting servers, storage systems, and networking equipment.
- Telecommunications: Securing critical communications infrastructure.
- Industrial Automation: Ensuring uninterrupted operation of production lines and control systems.
- Healthcare Facilities: Protecting medical equipment and patient data.
- Commercial Buildings: Safeguarding critical loads such as elevators, HVAC systems, and security systems.
The Articles You may Like
- Safeguard Your Electronics with a UPS Backup Power Supply for Home
- 5 Easy Ways to Wake up Lithium Battery
- Uninterruptible power supply – Wikipedia
- How Many Homes Can an Acre of Solar Panels Power
- How to Choose the Best Lithium Battery Pack for Your Needs
- Understanding Split Phase vs 3 Phase Power Systems
- How Lithium Battery for Solar Systems Transforms Energy Use
- Industrial ups power supply vs normal UPS
| Model | GT30K PLUS |
| Capacity | 30KVA/24KW |
| UPS Efficiency | >95% |
| Noise | 53dB~60dB(Distance 1 Meter) |
| Dimension(WxDxH mm) | 905x740x1220 |
| Weight(Kgs) | 425 |
| INPUT | |
| Voltage | 3 Phases 4 Wires, 208Vac/220Vac/440Vac/480Vac ± 25% |
| Frequency | 50Hz/60Hz±5% (Automatically) |
| Power Factor | ≥0.95 |
| OUTPUT | |
| Voltage | 3 Phases 4 Wires, 208Vac/220Vac/440Vac/480Vac ± 1% |
| Frequency | 50Hz/60Hz±0.05%(By Battery) |
| Harmonic Distortion | Linear load<3%, Non-linear load<5% |
| Imbalance Voltage | Balance load≤1%, Imbalance load≤3% |
| Phase Shift Angle | Balance load≤1°, Imbalance load≤2° |
| Transient Response | Output at 0~50%~100% ≤5%, response ≤ 10ms |
| Overload Capacity | 110%≥300Min, 125%≥10Min, 150%≥1Min |
| Crest Factor | 3:1 |
| Wave Form | Pure sine wave |
| Transfer Time | 0ms |
| BATTERY | |
| Type | Support VRLA Battery |
| D.C. Voltage | 384Vdc |
| Max. Charging Current | 0.2AxC10 |
| Charging Time(Standard) | 12hours |
| SYSTEM | |
| Protection | Input over-voltage, under-voltage; output overload, shortcircuit; Inverter over-temperature; Battery under-voltage,over-voltage |
| IP Protection | IP20 |
| Parallel Mode | N+1,N+X,can be in parallel with different power capacity |
| Software Interface | Windows9x,2000,NT,ME,XP,Linux,Novell,Macosx,NT4.0 |
| Meantime Between Failures | 300,000Hours |
| ENVIRONMENT | |
| Operating Temperature | 0℃ to 40℃ |
| Humidity | 0~95% (non-condensing) |
| Altitude | <1000m (with increase of 100m,it will reduce output of 1%) max. 4000m |
| Storage Temperature | -25℃ to 55℃ |
| MANAGEMENT | |
| Communication Interface | RS232/RS485 |
| Remote Signaling | Dry contact (battery low,battery discharging,bypass/fault),EPO |
| Remote Control | EPO and bypass |
| SNMP Card | Power management from SNMP manager and web browser |
