PIR1K 2u rack mount dc to ac pure sine wave power inverter 1000w 24v
Power Inverter | 1000W | 2U | 24VDC | 120Vac or 230Vac | Single Phase | Pure Sine Wave
Prostar PIR1K 2u rack mount dc to ac pure sine wave power inverter 1000w 24v can provide reliable and efficient power conversion for telecom applications. This essential component ensures a stable and uninterrupted power supply to critical telecommunication equipment, even in remote or off-grid locations.
Designed rack mount type, this can save valuable floor space in data centers and other facilities with limited space availability.
The power inverter 1000w efficiently converts direct current (DC) power from batteries or other DC sources into alternating current (AC) power that is compatible with the telecom equipment. It ensures a seamless transition between power sources and eliminates the risk of power disruptions.
Power Inverter 1000W Features
1.Compact Design
Rack mount power inverter can fit into standard equipment racks, allowing for efficient use of space in crowded environments.
2.Pure Sine Wave Output
It produces a smooth and consistent AC (alternating current) output, similar to what you would find in a standard household electrical outlet.
3.Robust and Reliable Performance
The telecom power inverter is built with high-quality isolation transformer and features a rugged design to withstand harsh operating conditions.
4.Wide input voltage range (110V-300V)
It is allowing to work with different power sources or handle fluctuating voltage conditions. This wide input voltage range makes the inverter versatile and adaptable for different applications and power supply scenarios.
5. Boost and buck AVR for voltage stabilization
It helps to regulate and maintain a stable output voltage despite fluctuations or variations in the input voltage. This is particularly useful in situations where the input power source experiences voltage sags or dips.
6.LCD panel for comprehensive display
Front-panel LCD signals operating mode, load level, voltage, battery charge and estimated runtimes. Supports multiple advanced user setup and operating preferences.
7. Advanced Protection Mechanisms
These devices typically incorporate protective features such as overload protection, over-temperature protection, and short-circuit protection, ensuring safe and reliable operation.
8.Remote Monitoring and Control
It offers remote monitoring and control capabilities, allowing users to monitor performance, adjust settings, and receive notifications remotely.
Telecom Inverter 1000W Details
Error code reference
| Code | Description |
| E01 | Power amplifier over current |
| E02 | Output short circuit protection |
| E03 | Overload protection |
| E04 | Over temperature protection |
| E05 | Battery over voltage protection |
| E06 | Low battery voltage protection |
| E07 | Phase reverse protection |
| E08 | Low output voltage protection |
| E09 | Date of manufacture does not match |
| E10 | Battery power down, voltage drop |
The Articles You may Like
| Model | PIR1K | |||||
| Rated Power | 1000W | |||||
| INPUT | ||||||
| Voltage Range | 100V/110V/120V/127AC or 208V/220V/230V/240VAC(+25%,-36%) | |||||
| Frequency Range | 50/60 Hz±2.5Hz Auto | |||||
| OUTPUT | ||||||
| AC Voltage Regulation | 100V/110V/120V/127AC±0.5% or 208V/220V/230V/240VAC±0.5%（AC Mode±10%） | |||||
| Frequency | 50HZ/60HZ±0.5HZ Auto（AC Mode±2.5HZ） | |||||
| Surge Power | 3000W | |||||
| Battery Efficiency | 81% | |||||
| AC Efficiency | 93% | |||||
| Transfer Time | 8ms default, 4ms optional | |||||
| Waveform | Pure Sinewave | |||||
| BATTERY | ||||||
| Battery Voltage | 24VDC | |||||
| Floating Charge Voltage | 27.2VDC | |||||
| Overcharge Protection | 30.0VDC | |||||
| AC Charge Current | 0-20A Adjustable (20A default) | |||||
| PROTECTION | ||||||
| Battery Reversal | Optional | |||||
| Output Short Circuit | AC mode:Jump fuse, Inverter mode: Shut down | |||||
| Overload | Full load 100%, inverter alarm. Overload 120%, inverter shut down output in 10s. Once the load back to normal, inverter recovers output. | |||||
| High AC Voltage | Turn off AC, turn to inverter mode automatically | |||||
| Low DC Voltage | Inverter shuts down automatically, once the AC recover, inverter turns on and charges automatically | |||||
| Over Temperature | Power Off | |||||
| ENVIRONMENT | ||||||
| Humidity | 15～93%（No condensation） | |||||
| Temperature | -10℃ ~ 50℃ | |||||
| Altitude | ≤3000m | |||||
| Communication | RS232(default),USB, RS485, SNMP (Optional) | |||||
| MECHANICAL SPECIFICATIONS | ||||||
| Dimension, DxWxH (mm) | 483×390×88 [2U] | |||||
| Net Weight (Kgs/PC) | 12.00 | |||||
