Prostar PIL3K low frequency pure sine wave 24v 3000w inverter for home
Power Inverter | 3000W | 24Vdc | Pure Sine Wave Output
Prostar PIL3K low frequency pure sine wave 24v 3000w inverter is built-in smart battery charger allows for you to use your existing grid power to maintain a charge on your batteries.
Prostar PIL3K low frequency pure sine wave 24v 3000w inverter is capable of producing 110Vac/120Vac/220Vac/230Vac. It will work virtually anywhere in the world, with the ability to auto detect 50 or 60 hz.
Low frequency pure sine wave power inverter is great for your emergency battery backup for when the grid goes down with an unnoticeable transfer time of 8 milliseconds, or for use as a standalone off-grid system.
Prostar PIL3K low frequency pure sine wave 24v 3000w inverter does not produce any power, the power is provided by the DC source. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, input/output voltage and frequency, and acceptable input voltage based on different applications.
24V 3000W Inverter Features
Advanced all-digital CPU control
The intelligent CPU control system guarantees precise and efficient power conversion, optimizing performance.
Built-in Intelligent Charger
It comes with a smart charger that provides safe and optimal charging for your batteries.
Wide input voltage range (110V-300V)
The inverter can handle a wide range of input voltages, allowing it to adapt to different power sources.
Special Protection method
The inverter incorporates multiple safety features to protect against overheating, under and over voltage charging, and short circuits.
Well unattended function
In the event of a power outage, the inverter automatically switches to battery power until low voltage is detected, then safely shuts down. Once main power is restored, it seamlessly switches back to AC power while simultaneously recharging the battery, requiring no manual intervention.
High Efficiency and Energy Saving
The inverter is designed to be highly efficient, minimizing energy wastage and saving power.
Auto restart while AC is recovering
After a power interruption, the inverter automatically restarts when the AC power supply is stable again.
Excellent microprocessor control guarantees high reliability
The power inverter’s sophisticated microprocessor ensures consistent and reliable performance.
Boost and buck AVR for voltage stabilization
It employs an Automatic Voltage Regulator (AVR) to stabilize output voltage, safeguarding connected devices from voltage fluctuations.
Cold start function
The inverter can start without AC power, allowing it to function even when the main power is unavailable.
LCD panel for comprehensive display
The LCD screen provides clear and comprehensive information about the inverter’s status and settings.
Adjustable charging voltage and charging current
Users have the flexibility to select different charging voltages (ranging from 13.0V to 14.5V) and charging currents (ranging from 0A to 60A) to suit various battery types and ensure optimal battery life.
Inverter Schematic Diagram
LCD Display
The built-in LCD screen provides real-time monitoring of crucial information. Users can conveniently view the input voltage, output wattage, battery level, and any activated protection modes. This comprehensive display allows for easy monitoring and helps users make informed decisions about their power usage.
Inverter Error Code Information
| Code | Description |
| E01 | Power amplifier over current |
| E02 | Output short circuit protection |
| E03 | Overload protection |
| E04 | Over temperature protection |
| E05 | Battery over voltage protection |
| E06 | Low battery voltage protection |
| E07 | Phase reverse protection |
| E08 | Low output voltage protection |
| E09 | Date of manufacture does not match |
| E10 | Battery power down, voltage drop |
The Articles You may Like
| Model | PIL3K-24 | ||||||||||
| Rated Power | 3000W | ||||||||||
| INPUT | |||||||||||
| Voltage Range | 100V/110V/120V/127AC or 208V/220V/230V/240VAC(+25%,-25%) | ||||||||||
| Frequency Range | 50/60 Hz±2.5Hz Auto | ||||||||||
| OUTPUT | |||||||||||
| AC Voltage Regulation | 100V/110V/120V/127AC±0.5% or 208V/220V/230V/240VAC±0.5%（AC Mode±10%） | ||||||||||
| Frequency | 50Hz/60Hz±0.5Hz Auto（AC Mode±2.5Hz） | ||||||||||
| Power Factor | 1.0 | ||||||||||
| Surge Power | 9000W | ||||||||||
| Capable Of Starting Electric Motor | 5HP | ||||||||||
| Battery Efficiency | 85% | ||||||||||
| AC Efficiency | 93% | ||||||||||
| Transfer Time | 8ms default, 4ms optional | ||||||||||
| Waveform | Pure Sinewave | ||||||||||
| BATTERY | |||||||||||
| Battery Voltage | 24VDC | ||||||||||
| Floating Charge Voltage | 27.2VDC | ||||||||||
| Overcharge Protection | 30.0VDC | ||||||||||
| AC Charge Current | 12A-60A Adjustable (60A default) | ||||||||||
| PROTECTION | |||||||||||
| Battery Reversal | Optional | ||||||||||
| Output Short Circuit | AC mode:Jump fuse, Inverter mode: Shut down | ||||||||||
| Overload | Full load 100%, Inverter alarm. Overload 120%, Inverter shut down output in 10s. Once the load back to normal, Inverter recover output. | ||||||||||
| High AC Voltage | Turn off AC,turn to Inverter mode automatically | ||||||||||
| Low DC Voltage | Inverter shut down automatically,Once the AC recover, Inverter turn on and charge automatically | ||||||||||
| Over Temperature | Power Off | ||||||||||
| ENVIRONMENT | |||||||||||
| Humidity | 15～93%（No condensation） | ||||||||||
| Temperature | -10℃ ~ 50℃ | ||||||||||
| Altitude | ≤3000m | ||||||||||
| Communication | USB, RS232/485, SNMP (Optional) | ||||||||||
| MECHANICAL SPECIFICATIONS | |||||||||||
| Dimension, DxWxH (mm) | 550x295x205 | ||||||||||
| Net Weight (Kgs/PC) | 25.8 | ||||||||||
| Product specifications are subject to change without further notice. | |||||||||||
